01
Edge-to-cloud data path
Signals are acquired near the machine, processed into defined measurements and transferred through the available plant network. Local buffering protects data continuity when communication is interrupted.
- Sensors and edge acquisition
- Local signal processing
- Secure network transport
- Database and retention
- Dashboard and user access
- Alerts and reports
02
Dashboard information hierarchy
The first screen should show what needs attention. Detailed screens should then expose machine points, channel values, trends, event history and diagnostic records.
- Plant and machine overview
- Normal, warning and danger status
- Latest event
- Channel-level detail
- Time-range trend selection
- Downloadable reports
03
Network and security planning
Industrial monitoring must follow the customer's IT and cybersecurity requirements. Deployment can use a plant server, VPN, private cloud or approved public-cloud environment.
- Defined outbound connections
- User authentication and roles
- TLS-encrypted transport
- Audit and event records
- Data ownership and retention policy
04
Remote monitoring applications
Remote dashboards are useful where assets are distributed, specialist support is centralized or maintenance teams need access outside the control room.
- Multiple production sites
- OEM equipment fleets
- Remote pumping stations
- Marine and utility equipment
- Service and warranty support
