Simultaneous channels
Preserve relative timing for multi-point comparison, phase-related investigation and transient capture.
Four-channel dynamic signal acquisition
Q-DAQ Edge
24-bit vibration DAQ for live measurement, recording and post-analysis.
Designed around IEPE accelerometers, synchronized acquisition and retention of calibrated raw time data. Use it for machine testing, troubleshooting, product validation and focused online monitoring.
4simultaneous inputs
24-bitacquisition
256 kS/smaximum selectable rate
IEPEsensor support
Technical specification
Clear measurement architecture.
Specifications below describe the current platform configuration. Final commercial configuration is confirmed against the application.
Dynamic inputs4 simultaneous channels
Digital resolution24-bit acquisition path
Selectable sample rates8, 16, 32, 64, 128 and 256 kS/s
Sensor excitationIEPE configuration supported
Input signal optionsIEPE accelerometer and voltage input workflow
Time-domain recordingCalibrated raw time signal retained
Analysis viewsTime, FFT, octave, spectrogram and trend
Engineering unitsAcceleration, velocity and displacement workflow
DeploymentEngineering PC or application-specific server architecture
ExportsCSV, plots and report-ready results
Why the signal path matters
A DAQ system is more than its maximum sample rate.
Useful measurement depends on the complete path from transducer power and anti-alias filtering to synchronized recording, engineering units and post-processing.
Raw time retention
Repeat FFT, filtering and derived-unit processing without repeating the physical test.
Visible analysis settings
Show sample rate, FFT size, record length, resolution, window and averaging with the result.
Application configuration
Select channels, sensors, bandwidth and storage from the machine—not from a generic package.
Applications
One focused platform for measurement and monitoring work.
Machine testing
Pumps, motors, fans and gearboxes
Capture bearing locations and directions for commissioning, troubleshooting and after-maintenance comparison.
R&D validation
Product vibration and NVH
Record synchronized accelerometer, microphone and speed-related signals according to the configured front end.
Condition monitoring
Focused online points
Stream overall values, waveform, FFT and event records into a machine-health workflow.
Configure Q-DAQ Edge
Request technical proposal ↗
